Micronized Red

Micronix IronOxide Red 4130M , Micronized Iron Oxide Red 4130M

Micronix IronOxide Red 4130M , Micronized Iron Oxide Red 4130M

Chemical Formula: Fe2O3 ; Product Form: Red Pigment in Micronized Powder ;
Color Index: Pigment Red 101 ( 77491 ) , CAS No.: 1309-37-1 , EINECS No.: 215-168-2 ;
Dispersibility (Hegman): 8 Grade , Characteristics of Particle Size < 16um ;
Delivery as FOB, DAF, CIF, CIP Base TT, L/C, D/P Payment term, Standard Palletized Suited for container loading.
Product description：Our high PERFORMANCE Micronized iron oxide pigments have the characteristics of particle size < 16um, grade 8 Hegmen ( Hegmans > 7um ), that means stronger tinting strength, excellence dispersibility, higher glossary, typical micronix yellow 3920, 313M, 810M, micronix red 4110M, 4130M, micronix black 4330M, 5140M, etc at client's choice.
INQUIRY

Our GREEFIELD micronized iron oxide pigments are further processed by ultra-fine mill with synthetic iron oxide to micron grade, which have the characteristics of particle size < 16um, grade 8 Hegmen ( Hegmans > 7um ), that means stronger tinting strength, higher glossary, better color consistency between each lot, more bright color; excellence dispersibility, reduce dispersing time, improve production efficiency, reduce dosage; full range red, yellow, black series types at client's choice; they are suitable for high performance applications widely such as coating, paint, ink, plastic, leather, paper cosmetics, electronics, biological pharmaceuticals, etc.

Advantages:

1).Bright-colored exquisite powder;

2).Good weatherability; Lightfastness, heat-resistant and alkali resistant;

3).Strong tinting power, excellent covering ability and fine dispersion;

4).We can supply iron oxide with different color, specifications and packing base on client's request.

Mainly Application:

1).Constructions: colorant for asphalt and concrete, terrazzo, masonry block, bricks, paving slabs, brick paver, architectural, ready-mix concrete, roof tiles, sand-lime bricks and walling blocks etc;

2).Paint and coating: water-based exterior and interior wall coating,oil paint primer and finish paints and anticorrosion paints etc;

3).Plastic and rubber: thermosetting plastic and thermoplastic and rubber track etc;

4).Others: paper, leather, ceramics, cosmetic and medicine etc.

Material Technical Data Sheet for Micronized Iron Oxide Red:

Color value & Tinting strength	Unit	Specification	Test Method
Mass Tone DEabL		≤ 1.2	ISO787-1
Tint Tone DEabL		≤ 1.0	ISO787-24
Relative tinting strength	%	97 ~ 103	ISO787-24

Technical Data	Unit	Specification	Test Method
Fe2O3 Content	%	≥ 96.0	ISO1248
Matter Volatile at 105℃	%	≤ 1.0	ISO787-2
Water Soluble Salts	%	≤ 0.3	ISO787-3
Residue on 45mm Mesh	%	≤ 0.008	ISO787-7
PH Value		4.5 ~ 8.0	ISO787-9
Oil Absorption	g/100g	15 ~ 25	ISO787-5
Ignition loss (1,000℃, ½ h)	%	≤ 1.0	DIN55913
Density	g/cm3	5.05	ISO787-10
Tamped Density	g/cm3	1.10	ISO787-11
Dispersibility ( Hegman )	μm	15 / 20 / 25	ISO787-20
Predominant Particle Size	μm	0.17	Electron Micrographs
Particle Shape		Spherical	Electron Micrographs
Standard Package	20kgs/bag , 25kg/bag , 50lb/bag base on standard palletized.
Transportation and Storage	Protect against weathering. Store in a dry place and avoid extreme fluctuations in temperature. Special conditions for opened packaging: Close bags after use to prevent the absorption of moisture and contamination.
Safety	The product is not classified as hazardous under EC 1907/2006 & EC 1272/2008.
